Din Abrader

Din Abrader:

This top quality and highly popular abrasion tester will allow you to measure the abrasion resistance of rubbers (vulcanized thermo set rubbers and thermoplastic elastomers) that are subject to abrasive/frictional wear on their actual service. Since wear is always a result of abrasion, different test methods have been developed for the simulation of long-term wear.

Standard:

DIN 53516. JIS K6369 ,GB/T 20991.GB 20265-2006.GB20266-2006.SATRA TM174.BS 903.JIS K6264.GB/T9867.ISO4649

Applicable Industry:

CE Plastic and Rubber Din Abrasion Tester, DIN Abrasimeter applied to test leather performance in shoes, clothing, luggage handbag industry, research laboratories, commodity inspection, arbitration and technical supervision departments.

Main Feature:

With a small sample, save time, friction way of non-repetition, low noise, high efficiency, good reproducibility and easy to operate and so on.

Parameters:

The test piece: φ16mm, 6 ~ 15mm (D)

Clamp load: 2.5N

Weight load: 2.5N, 5N

The fixture lateral displacement volume: 4.2mm / wheel every lap

Abrasive cloth: 60 #

Roller Diameter: 150mm

Roller Length: 460mm

The roller speed: 40rpm

predetermined stroke: 40m / 20m

Wear Speed: 0.32m / sec

Inclination: 3 ° test piece and the roller support shaft vertical angle

Volume: 70 × 30 × 30cm

Weight: 61kg

Power source: 1∮, AC220V, 3A
